PTING Intelligent Sandblasting Machine——Auto Parts Fork Sandblasting Solution

On the automobile gearbox, the gearshift synchronous ring relies on friction to achieve synchronization. After spraying a layer of aluminum-molybdenum alloy, it can make the gear have a self-locking function when it is working, ensuring safe and stable driving. Gear manipulation performance, reliability and life have a great influence, therefore, in product design, CU-AL and NI-AL thermal spraying treatment on the working surface of the fork can improve the wear resistance and lubricity of the fork and fatigue strength.

On the automobile gearbox, the gearshift synchronous ring relies on friction to achieve synchronization. After spraying a layer of aluminum-molybdenum alloy, it can make the gear have a self-locking function when it is working, ensuring safe and stable driving. Gear manipulation performance, reliability and life have a great influence, therefore, in product design, CU-AL and NI-AL thermal spraying treatment on the working surface of the fork can improve the wear resistance and lubricity of the fork and fatigue strength.

In the manufacturing process of the fork, in order to ensure the adhesion of the thermal spray coating, the sandblasting of the base material on the sprayed surface of the fork is very important, and its sandblasting rough shape and RA value must be consistent. Therefore, sandblasting the workpiece The angle, pressure, time, coverage, and abrasive sorting all have very strict requirements, which cannot be fulfilled by traditional sandblasting equipment.

In response to customer requirements, PTING Technology develops and customizes high-precision intelligent auto parts sandblasting machines for customers. Its main features are as follows:

1. The servo manipulator is used to precisely position the spray gun and set the sandblasting time accurately.

2. It adopts pressure-feeding sandblasting, cooperates with material level sensor, and maintains pressure to achieve a shorter start-up time of the spray gun;

3. Three-stage groups of drum sieve separation, cyclone separation, and filter element dust removal are used to separate and remove dust from abrasives, ensuring the consistency of abrasives to a high degree;

4. Customized tooling cooperates with intelligent PLC programs to realize fast switching programs for different types of parts.

5. Wide range of applications: shift forks, synchronous rings, piston rings, brake discs, etc.
